Herzlich Willkommen in ProfEC's One Stop Wind Shop!

ZXTM Horizontal Wind Profiler - Monthly rental service
• 17 horizontal ranges with configurable dwell times
• Wind characteristics: wind speed, shear, veer, wind yaw misalignment, turbulence, rotor equivalent wind speed (REWS), windflow complexity
• Wind speed range: < 0.5-45 m/s (wind loading survivability up to 70 m/s)
• Accuracy: Direction - 0.5°, Speed - 0.1 m/s
• 50 Hz /20 ms measurements (50 measurements per second)
• Measurement range: 10m - 550m
• 3 year warranty included
• no factory maintenance or calibration required  in 3 year service period

• 12x pulse counters IN
• 7x analog voltage IN
• Requires external 12VDC power supply
• 7x configurable 'Flex' Channels (Analog or Counter) with optional signal conditioning modules (P-SCMs)
• 512 MB SD Card, non-volatile flash memory
• Resolution: 16 bit ad
• Accuracy: 0.04 % of full scale
• LCD with 16 button keypad
• 2x RS485 serial communication on wiring panel

ZXTM Horizontal Wind Profiler
• 17 horizontal ranges with configurable dwell times
• Wind characteristics: wind speed, shear, veer, wind yaw misalignment, turbulence, rotor equivalent wind speed (REWS), windflow complexity
• Wind speed range: < 0.5-45 m/s (wind loading survivability up to 70 m/s)
• Accuracy: Direction - 0.5°, Speed - 0.1 m/s
• 50 Hz /20 ms measurements (50 measurements per second)
• Measurement range: 10m - 550m
• 3 year warranty included
• no factory maintenance or calibration required  in 3 year service period

• Certified verification of Remote Sensing Device (some may call it "calibration")
• Carried out in accordance to the IEC 61400-50-1 and IEC 61400-50-2, accredited as per ISO 17025
• Conducted at a 200m reference mast
• Procedure warrants lowest uncertainties, highest accuracy, and compliance in line with IEC, FGW and IEA

• Module for 10 Ports / RS485 2-wire / Configurable UOUT
• Stabilised and ripple-free voltage output individually configurable
• 10 individually configurable ports
• One stabilised and ripple-free output with active current limit (110 mA)
• One configurable bus-termination resistor (120 Ω) for two-wire RS485 bus setup (half duplex)
• Each terminal comprises overvoltage protection

WindCube Winter Kit
• Leosphere accessory for WindCube v2.1
• Tilted surface for low snow retention
• Active heating element with 2 selectable power modes (90 or 120W)
• Easy installation
• Tested in harsh weather conditions with snow and ice at -20°C
• Suitable for remote and hard-to-reach places
• Input power supply: 24.5 - 27 VDC

• 800...1050 hPa
• Calibrated (ISO 17025) with traceable calibration certificate and mark (ilac-MRA)
• Output signal: 0...5V DC
• Connector included
• Supply Voltage: 8 ... 32 V
• Operating temperature: -40 ... 105°C

• 4.3352.10.400 - unbeheizt
• Class A compliant according to IEC 61400-12-1 & 61400-12-1 Ed.2
• W/o heating
• Measurement Range: 0.3...75 m/s
• Outputs: RS485 / ASCII / MODBUS
• Option for connecting a bus-compatible wind vanes and anemometers in parallel (daisy chain)
• Measures next to wind speed also:
   Air pressure: 300 ... 1100 hPa (Accuracy: ±1 hPa @ 20 °C)
   Indication: Measuring range: -89.9 ... +89.9° (Accuracy: ±1 °)
   Vibration: Measuring range: 0 ... 50 Hz (Accuracy: ±0.4 Hz)
   Acceleration: Measuring range: ±8 g (Accuracy: ±30 mg)

• 12V, 50 Ah
• Maintenance free, Non-spillable
• Including safety data sheet for aviation transport
• Low self-discharge ratio
• Special deep cycle battery designed for intensive cyclic discharge usage

Service includes:
• Inspection
• Inspection report
• Subsequent to an inspection, the Client can decide if the sensor shall receive a Certified Maintenance and Refurbishment Service or, if needed, repair.

ZX 300e LIDAR
• IEC classified from 21 to 200 m
• Accuracy class and standard uncertainty of 0% at all heights
• Measurement range: Accuracy and availability proven up to 300m
• New Continuous Wave algorithms and hardware
• Cup-equivalent turbulence intensity and wind direction sensing

• Includes mounting of sensor-specific connectors / plugs / jacks
• Sensor-specific wiring scheme included
• Line-to-line calibration according to IEC, MEASNET and FGW recommendations
• Labelling provided for easy plug&play installation on site

• Module for 10 Ports / RS485 2-wire / Configurable UOUT
• Stabilised and ripple-free voltage output individually configurable
• 10 individually configurable ports
• One stabilised and ripple-free output with active current limit (110 mA)
• One configurable bus-termination resistor (120 Ω) for two-wire RS485 bus setup (half duplex)
• Each terminal comprises overvoltage protection

• Spectral range: 360 to 1120 nm (wavelengths where response is 10% of max)
• 0...2000 W m-2 (full sunlight ≈1000 W m-2)
• Incl. calibration certificate
• Accuracy: ±5% for daily total radiation
• Self-powered
• For Global Horizontal Irradiance (GHI) measurements (W/m2)

• USB (2.0) interface with up to 2GB flash storage
• Allows Plug&Play field upgrades and configuration by using our Device Configuration utility
• Expands data logger storage by 2 GB, tandem operation with Compact Flash card possible
• Shuttles data, OS, and program files between Campbell Scientific dataloggers and a PC
• For CR800, CR850, CR1000, CR6, CR3000, CR5000, CR9000(X)

• M83575
• 3 Ports: Pull-Up 5.1kOhm, Compact Vane
• 3 Ports: First Class Vane etc., 10mA
• 2 Ports: Pull-Down 10kOhm
• 2 Ports: Configurable, open
• RS485: Resistors for Biasing and Termination
• Output: 5V/100mA
• Supply: 9 to 32VDC

For all Thies First Class sensors anemometer and wind vanes
• OEM recommended in order to maintain warranty

• Typical range of operation: 0.0 .. 1.8mm/minute rainfall intensity (normal rainfall intensity is in the range 0.1 ... 0.5 mm/minute)
• Accuracy: +/-2%
• Resolution: 0.20mm per “tip” (0.10mm, 0.25 and 0.50mm also available)
• Incl. individual calibration certificate
